配对交易与统计套利：从协整检验到实盘执行的完整指南

import numpy as np
import pandas as pd
import statsmodels.api as sm
from statsmodels.tsa.stattools import adfuller

def engle_granger_test(price_A, price_B):
    """
    Engle-Granger协整检验
    返回：协整残差、p值
    """
    # Step 1: OLS回归
    X = sm.add_constant(price_B)
    model = sm.OLS(price_A, X).fit()
    spread = model.resid

    # Step 2: ADF检验残差平稳性
    adf_result = adfuller(spread, autolag='AIC')
    adf_stat = adf_result[0]
    p_value = adf_result[1]
    critical_values = adf_result[4]

    # 判断协整（1%显著性水平）
    is_cointegrated = p_value < 0.01 and adf_stat < critical_values['1%']

    return {
        'spread': spread,
        'adf_stat': adf_stat,
        'p_value': p_value,
        'is_cointegrated': is_cointegrated,
        'hedge_ratio': model.params[1]  # β系数
    }

# 示例使用
result = engle_granger_test(price_A, price_B)
print(f"ADF统计量: {result['adf_stat']:.4f}")
print(f"p-value: {result['p_value']:.4f}")
print(f"对冲比例(β): {result['hedge_ratio']:.4f}")
print(f"是否协整: {result['is_cointegrated']}")

from statsmodels.tsa.vector_ar.vecm import coint_johansen

def johansen_test(price_matrix, det_order=0, k_ar_diff=1):
    """
    Johansen协整检验（适用于多只股票）
    price_matrix: T×N 矩阵，T为时间长度，N为股票数量
    """
    result = coint_johansen(price_matrix, det_order, k_ar_diff)

    # 输出结果
    print("特征值和特征向量:")
    print(result.eig)
    print("\n协整关系数量检验:")
    print(f"Trace统计量: {result.lr1}")
    print(f"Max统计量: {result.lr2}")

    # 判断协整关系数量（5%显著性水平）
    trace_critical = result.cvt[:, 1]  # 5%临界值
    num_coint = sum(result.lr1 > trace_critical)

    return {
        'num_coint': num_coint,
        'eigenvalues': result.eig,
        'trace_stat': result.lr1,
        'max_stat': result.lr2
    }

def preliminary_screening(stock_list, start_date, end_date):
    """
    初步筛选：行业相同、市值相近、流动性好
    """
    # 获取股票基本信息
    stock_data = get_stock_info(stock_list, start_date, end_date)

    # 筛选条件
    conditions = [
        ('industry', 'same'),  # 同一行业
        ('market_cap', lambda x: abs(x - x.median()) / x.median() < 0.5),  # 市值相近
        ('avg_volume', lambda x: x > 1e6),  # 日均成交量>100万
        ('price_range', lambda x: (x > 5) & (x < 500))  # 股价在5-500之间
    ]

    screened_stocks = apply_filters(stock_data, conditions)
    return screened_stocks

def calculate_similarity(price_data):
    """
    计算股票之间的相似度
    返回：相似度矩阵
    """
    stocks = price_data.columns
    n = len(stocks)
    similarity_matrix = np.zeros((n, n))

    for i in range(n):
        for j in range(i+1, n):
            # 1. 相关系数
            corr = price_data[stocks[i]].corr(price_data[stocks[j]])

            # 2. 协整检验p-value
            coint_result = engle_granger_test(price_data[stocks[i]], price_data[stocks[j]])
            p_value = coint_result['p_value']

            # 3. 距离度量（欧几里得距离）
            distance = np.linalg.norm(price_data[stocks[i]] - price_data[stocks[j]])

            # 综合相似度得分（越小越好）
            similarity_score = (1 - corr) * 0.3 + p_value * 0.5 + distance * 0.2

            similarity_matrix[i, j] = similarity_matrix[j, i] = similarity_score

    return similarity_matrix

from sklearn.cluster import AgglomerativeClustering

def cluster_stocks(similarity_matrix, n_clusters=10):
    """
    层次聚类：将相似的股票分组
    """
    # 将相似度矩阵转换为距离矩阵
    distance_matrix = similarity_matrix

    # 层次聚类
    clustering = AgglomerativeClustering(
        n_clusters=n_clusters,
        affinity='precomputed',
        linkage='average'
    )
    labels = clustering.fit_predict(distance_matrix)

    # 输出分组结果
    clusters = {}
    for i, label in enumerate(labels):
        if label not in clusters:
            clusters[label] = []
        clusters[label].append(i)

    return clusters

def calculate_z_score(spread, window=20):
    """
    计算价差的Z-Score
    window: 滚动窗口长度
    """
    spread_mean = spread.rolling(window=window).mean()
    spread_std = spread.rolling(window=window).std()

    z_score = (spread - spread_mean) / spread_std

    return z_score

# 可视化
import matplotlib.pyplot as plt

fig, axes = plt.subplots(2, 1, figsize=(12, 8))

# 子图1：价差
axes[0].plot(spread.index, spread.values)
axes[0].axhline(spread.mean(), color='red', linestyle='--', label='Mean')
axes[0].fill_between(spread.index,
                      spread.mean() - 2*spread.std(),
                      spread.mean() + 2*spread.std(),
                      alpha=0.2, color='red', label='±2σ')
axes[0].set_title('Spread')
axes[0].legend()

# 子图2：Z-Score
axes[1].plot(z_score.index, z_score.values)
axes[1].axhline(0, color='black', linestyle='-', alpha=0.3)
axes[1].axhline(2, color='red', linestyle='--', label='+2σ')
axes[1].axhline(-2, color='green', linestyle='--', label='-2σ')
axes[1].fill_between(z_score.index, -2, 2, alpha=0.1, color='gray')
axes[1].set_title('Z-Score')
axes[1].legend()

plt.tight_layout()
plt.savefig('z_score_signal.png')

class PairsTradingSignal:
    def __init__(self, entry_threshold=2.0, exit_threshold=0.5, stop_loss=3.0):
        self.entry_threshold = entry_threshold
        self.exit_threshold = exit_threshold
        self.stop_loss = stop_loss

    def generate_signal(self, z_score):
        """
        生成交易信号
        返回：1(做多价差), -1(做空价差), 0(平仓)
        """
        signal = pd.Series(0, index=z_score.index)

        position = 0  # 当前持仓：0(空仓), 1(多价差), -1(空价差)

        for i in range(1, len(z_score)):
            if position == 0:
                # 空仓状态，检查入场信号
                if z_score.iloc[i] < -self.entry_threshold:
                    position = 1
                    signal.iloc[i] = 1
                elif z_score.iloc[i] > self.entry_threshold:
                    position = -1
                    signal.iloc[i] = -1

            elif position == 1:
                # 持有多价差，检查出场信号
                if abs(z_score.iloc[i]) < self.exit_threshold:
                    position = 0
                    signal.iloc[i] = 0
                elif z_score.iloc[i] < -self.stop_loss:
                    position = 0
                    signal.iloc[i] = 0  # 止损

            elif position == -1:
                # 持有空价差，检查出场信号
                if abs(z_score.iloc[i]) < self.exit_threshold:
                    position = 0
                    signal.iloc[i] = 0
                elif z_score.iloc[i] > self.stop_loss:
                    position = 0
                    signal.iloc[i] = 0  # 止损

        return signal

from pykalman import KalmanFilter

def kalman_filter_spread(price_A, price_B):
    """
    使用卡尔曼滤波动态估计对冲比例
    """
    # 观测矩阵：价格B
    observation_matrix = price_B.values.reshape(-1, 1)

    # 状态矩阵：对冲比例
    transition_matrix = np.array([[1]])

    kf = KalmanFilter(
        transition_matrices=transition_matrix,
        observation_matrices=observation_matrix
    )

    # 状态：hedge_ratio
    state_means, _ = kf.filter(price_A.values)
    hedge_ratio_dynamic = state_means[:, 0]

    # 动态价差
    spread_dynamic = price_A - hedge_ratio_dynamic * price_B

    return spread_dynamic, hedge_ratio_dynamic

from scipy.optimize import minimize

def fit_ou_process(spread):
    """
    拟合Ornstein-Uhlenbeck过程
    dX_t = κ(μ - X_t)dt + σdW_t
    """
    # 离散化：X_{t+1} - X_t = κ(μ - X_t)Δt + σε_t
    dt = 1  # 日频数据

    def ou_likelihood(params):
        """OU过程的对数似然函数"""
        kappa, mu, sigma = params

        # 预测值
        X_pred = mu + (spread[:-1] - mu) * np.exp(-kappa * dt)

        # 残差
        residuals = spread[1:] - X_pred

        # 对数似然
        log_likelihood = -0.5 * (np.log(2*np.pi*sigma**2) + (residuals/sigma)**2).sum()

        return -log_likelihood  # 最小化负对数似然

    # 初始值
    x0 = [1.0, spread.mean(), spread.std()]

    # 优化
    result = minimize(ou_likelihood, x0, method='L-BFGS-B',
                      bounds=[(0.01, 10), (None, None), (0.01, 10)])

    kappa, mu, sigma = result.x

    # 半衰期
    half_life = np.log(2) / kappa

    return {
        'kappa': kappa,  # 均值回归速度
        'mu': mu,        # 长期均值
        'sigma': sigma,   # 波动率
        'half_life': half_life  # 半衰期
    }

# 使用示例
ou_params = fit_ou_process(spread)
print(f"均值回归速度(κ): {ou_params['kappa']:.4f}")
print(f"半衰期: {ou_params['half_life']:.2f}天")

def calculate_transaction_cost(signal, price, commission=0.0003, slippage=0.001):
    """
    计算交易成本
    signal: 交易信号（1, -1, 0）
    price: 价格序列
    commission: 佣金比例
    slippage: 滑点比例
    """
    # 计算换手率
    turnover = signal.diff().abs()

    # 交易成本
    cost = turnover * price * (commission + slippage)

    # 累计成本
    cumulative_cost = cost.cumsum()

    return cumulative_cost

class PairsRiskMonitor:
    def __init__(self, spread, z_score, signal):
        self.spread = spread
        self.z_score = z_score
        self.signal = signal

    def monitor_risk(self):
        """风险监控"""
        risks = {}

        # 1. 最大回撤
        cumulative_return = (self.signal.shift(1) * self.spread.pct_change()).cumsum()
        drawdown = (cumulative_return - cumulative_return.cummax()) / cumulative_return.cummax()
        max_drawdown = drawdown.min()
        risks['max_drawdown'] = max_drawdown

        # 2. 当前Z-Score
        current_z = self.z_score.iloc[-1]
        risks['current_z_score'] = current_z

        # 3. 持仓时间
        holding_time = (self.signal != 0).sum()
        risks['holding_time'] = holding_time

        # 4. 止损触发
        stop_loss_triggered = abs(current_z) > 3.0
        risks['stop_loss'] = stop_loss_triggered

        return risks

    def generate_alert(self, risks, limits):
        """生成预警"""
        alerts = []

        if risks['max_drawdown'] < limits['max_drawdown']:
            alerts.append(f"最大回撤超限: {risks['max_drawdown']:.2%}")

        if risks['current_z_score'] > limits['z_score']:
            alerts.append(f"Z-Score过高: {risks['current_z_score']:.2f}")

        if risks['holding_time'] > limits['holding_time']:
            alerts.append(f"持仓时间过长: {risks['holding_time']}天")

        if risks['stop_loss']:
            alerts.append("触发止损！")

        return alerts

class PairsTradingBacktest:
    def __init__(self, price_A, price_B, signal, initial_capital=1e6):
        self.price_A = price_A
        self.price_B = price_B
        self.signal = signal
        self.initial_capital = initial_capital

    def run_backtest(self):
        """执行回测"""
        # 1. 计算持仓
        position_A = self.signal  # 做多A
        position_B = -self.signal  # 做空B（对冲）

        # 2. 计算收益
        return_A = self.price_A.pct_change()
        return_B = self.price_B.pct_change()

        portfolio_return = position_A.shift(1) * return_A + position_B.shift(1) * return_B

        # 3. 计算净值
        cumulative_return = (1 + portfolio_return).cumprod()
        net_value = self.initial_capital * cumulative_return

        return {
            'portfolio_return': portfolio_return,
            'cumulative_return': cumulative_return,
            'net_value': net_value
        }

    def calculate_performance(self, returns):
        """计算绩效指标"""
        # 1. 年化收益率
        total_return = returns.sum()
        trading_days = len(returns)
        annual_return = (1 + total_return) ** (252 / trading_days) - 1

        # 2. 夏普比率
        sharpe_ratio = returns.mean() / returns.std() * np.sqrt(252)

        # 3. 最大回撤
        cumulative = (1 + returns).cumprod()
        rolling_max = cumulative.cummax()
        drawdown = (cumulative - rolling_max) / rolling_max
        max_drawdown = drawdown.min()

        # 4. 胜率
        win_rate = (returns > 0).sum() / len(returns)

        # 5. 盈亏比
        avg_win = returns[returns > 0].mean() if (returns > 0).sum() > 0 else 0
        avg_loss = returns[returns < 0].mean() if (returns < 0).sum() > 0 else 0
        profit_loss_ratio = abs(avg_win / avg_loss) if avg_loss != 0 else 0

        return {
            'annual_return': annual_return,
            'sharpe_ratio': sharpe_ratio,
            'max_drawdown': max_drawdown,
            'win_rate': win_rate,
            'profit_loss_ratio': profit_loss_ratio
        }

## 六、实盘案例分析

### 6.1 案例：贵州茅台 vs 五粮液

**数据区间**：2020-01-01 至 2025-12-31

**协整检验结果**
```python
# 读取数据
price_A = pd.read_csv('600519.SH.csv')['close']  # 贵州茅台
price_B = pd.read_csv('000858.SZ.csv')['close']  # 五粮液

# 协整检验
result = engle_granger_test(price_A, price_B)
print(f"ADF统计量: {result['adf_stat']:.4f}")
print(f"p-value: {result['p_value']:.4f}")
print(f"对冲比例(β): {result['hedge_ratio']:.4f}")

def multi_pairs_backtest(pairs_list, initial_capital=1e6):
    """
    多配对组合回测
    pairs_list: [(stock_A, stock_B), ...]
    """
    n_pairs = len(pairs_list)
    capital_per_pair = initial_capital / n_pairs

    all_returns = []
    for stock_A, stock_B in pairs_list:
        # 获取数据
        price_A = get_price(stock_A)
        price_B = get_price(stock_B)

        # 生成信号
        spread = calculate_spread(price_A, price_B)
        z_score = calculate_z_score(spread)
        signal = generate_signal(z_score)

        # 回测
        bt = PairsTradingBacktest(price_A, price_B, signal, capital_per_pair)
        result = bt.run_backtest()
        all_returns.append(result['portfolio_return'])

    # 合并收益
    combined_return = pd.concat(all_returns, axis=1).sum(axis=1)

    return combined_return

def monitor_cointegration_breakdown(price_A, price_B, window=60):
    """
    监控协整关系瓦解
    使用滚动窗口检验
    """
    breakdown_dates = []

    for i in range(window, len(price_A)):
        # 滚动窗口数据
        price_A_roll = price_A[i-window:i]
        price_B_roll = price_B[i-window:i]

        # 协整检验
        result = engle_granger_test(price_A_roll, price_B_roll)

        # 判断是否瓦解（p-value > 0.05）
        if result['p_value'] > 0.05:
            breakdown_dates.append(price_A.index[i])

    return breakdown_dates

def walk_forward_optimization(price_A, price_B, param_grid, train_window=252, test_window=63):
    """
    滚动窗口优化：避免过拟合
    """
    results = []

    for start in range(0, len(price_A) - train_window - test_window, test_window):
        # 训练集
        train_A = price_A[start:start+train_window]
        train_B = price_B[start:start+train_window]

        # 测试集
        test_A = price_A[start+train_window:start+train_window+test_window]
        test_B = price_B[start+train_window:start+train_window+test_window]

        # 参数优化（在训练集上）
        best_param = optimize_param(train_A, train_B, param_grid)

        # 样本外测试
        test_return = backtest(test_A, test_B, best_param)

        results.append({
            'param': best_param,
            'train_period': (start, start+train_window),
            'test_return': test_return
        })

    return results
